Dual Axle Box Trailer in galvanised finish

• 10 x 5 EXTERNAL DIMENSIONS Hot Dipped Galvanized
• 3000 x 1500 x 335mm sides TDM Box Trailer Low Side
• FLOOR BASE: Checker plate 2.5mm
• PANELS: Thickness 2.5mm
• HYDRAULIC COUPLING: ADR Approved 50mm Quick release
• BRAKES: Single Axle Hydraulic
• CHASSIS: 50mm x 50mm 2.5mm RHS
• CROSS MEMBERS: 50mm x 50mm 2.5mm RHS
• DRAW BAR: 100mm x 50mm x 4.0mm RHS
• TAIL GATE: 330mm High thickness 2.0mm
• LIGHTS: ADR Approved LED Lights
• LED Number plate light: x 7 Flat Pin plug
• REFLECTORS: White x 2 + Amber x 4
• SAFETY CHAIN: ADR Approved Rated LC10N Long Link
• QUANTITY OF CROSS MEMBERS: 5 + 1
• SAFETY CATCHES (TAIL GATE): Rotating 360-degree type
• SUSPENSION: 6 Leaf rocker springs
• MUDGUARDS: Rolled 2 fold 2mm
• TIE RAILS: 25mm pipe
• AXLE: 2 x Solid Square 40mm
• HUBS: Ford LM Bearings
• WHEELS: 14” Ford white Steel with 185R14C Light truck tyres
• A.T.M.: 2000 kg
• Jockey wheel: 6” Swing back

Options:

• Add Galvanized Cage: Size 3000 x 1500 x 600mm High - 32 x 32 x 2mm RHS
• Mesh: 60 x 55 x 3.5mm
• Add Spare wheel mounted: 14” Ford white Steel with 185R14C Light truck tyres
• Add Registration Fees: Registration done in store, standard government charges apply
